TB2S+
The TB2S+ is a two-way floorstanding or bridge-mounted studio monitor with a transmission-line bass design, a 170mm bass driver and a 27mm silk dome tweeter. It suits broadcasters and engineers wanting a neutral nearfield monitor for larger rooms.
- Passive two-way monitor with ATL transmission-line bass loading
- 170mm doped alloy-chassis LF and 27mm silk dome HF
- Frequency response 40Hz-25kHz, 90dB sensitivity
- Recommended amplifier power 40-150W, 8 ohm nominal
- Two pairs of 4mm sockets for bi-wire or bi-amp use
- Pairs with the TLE1S active sub for surround setups
Kuvat
5Ilmoitukset
Tästä mallista ei vielä ole ilmoituksia
Kun joku myy mallin TB2S+, ilmoitukset ja myyntihistoria näkyvät täällä.
Myy samanlainenKuvaus
The TB2S+ is a passive two-way monitor that uses Advanced Transmission Line (ATL) bass loading rather than a ported or sealed cabinet. It pairs a 170mm doped alloy-chassis bass driver with a 27mm ferrofluid-cooled silk soft dome tweeter, crossing over at 2kHz. Compared with the smaller DB1S+, it offers higher maximum SPL and deeper, better-defined bass, which makes it suitable for larger listening spaces.
This '+' revision brings changes to the tweeter, the crossover and the damping inside the transmission line. The monitor can be stand-mounted or bridge-mounted, and it can be combined with the TLE1S active sub bass unit to form a surround monitoring system.
Connection is through two pairs of 4mm sockets, allowing either bi-wiring or bi-amping. The speaker has an 8 ohm nominal impedance, 90dB sensitivity and a recommended amplifier power of 40-150W. A 20 year warranty is available when the product is registered within 10 days of purchase, subject to terms.
Video
Tekniset tiedot
- Merkki
- PMC
- Malli
- TB2S+
- Luokka
- Studio › Studiomonitorit
Audio
- Frequency response
- 40Hz-25kHz
- Sensitivity
- 90dB 1W 1m
- Impedance
- 8 Ohm nominal
- Crossover frequency
- 2kHz
- Effective ATL length
- 1.5m 4.92ft
Drivers
- LF drive unit
- Doped 170mm alloy chassis
- HF drive unit
- 27mm, Silk soft dome, ferrofluid cooled
- Bass loading
- Advanced Transmission Line (ATL)
Inputs
- Input connectors
- 2 Pairs 4mm Sockets (Bi-Wire or Bi-Amp)
Power
- Recommended amp power
- 40-150W
Physical
- Height
- 400mm 15.76"
- Width
- 200mm 7.87"
- Depth
- 300mm 11.81"
- Weight
- 8.5 kg 18.7lbs
Warranty
- Extended warranty
- 20 years when registered within 10 days of purchase
