IB2S-A
The IB2S-A is a large active three-way studio monitor with a 10-inch carbon fibre/Nomex bass driver, a 75mm soft dome midrange and a 34mm soft dome tweeter. It has balanced analogue and AES3 digital inputs and is aimed at professional studio and mastering use.
- Active three-way monitor with ATL bass loading
- 10in carbon fibre/Nomex bass driver, 75mm midrange, 34mm tweeter
- Amplifier power: LF 565W, MF 200W, HF 200W per channel
- Balanced analogue and AES3 inputs for main and LFE, with throughs
- Frequency response 20Hz-25kHz; crossover at 380Hz and 3.8kHz
- 20 year warranty with registration within 10 days of purchase
Kuvat
7Ilmoitukset
Tästä mallista ei vielä ole ilmoituksia
Kun joku myy mallin IB2S-A, ilmoitukset ja myyntihistoria näkyvät täällä.
Myy samanlainenKuvaus
The IB2S-A is a self-powered three-way monitor built around PMC's Advanced Transmission Line (ATL) bass loading, with an effective ATL length of 2.4m. A 250mm carbon fibre/Nomex piston driver handles low frequencies, a 75mm soft dome covers the midrange and a 34mm soft dome tweeter handles the highs. The crossover points are 380Hz and 3.8kHz, and the stated frequency response is 20Hz-25kHz.
Each speaker contains its own amplification: 565W for the low-frequency driver, and 200W each for the midrange and the tweeter. Inputs include balanced analogue and AES3 digital connections for both the main and LFE feeds, each with a through connection. The digital input accepts 96kHz 24-bit AES3, and analogue input sensitivity can be selected from +4dBu to +20dBu. A digital remote volume control is mentioned in a user testimonial, along with an onboard DA converter.
The cabinet is 740mm high, 330mm wide and 549mm deep and weighs 46.5kg. A 20 year warranty is available when the product is registered within 10 days of purchase, subject to terms.
Video
Tekniset tiedot
- Merkki
- PMC
- Malli
- IB2S-A
- Luokka
- Studio › Studiomonitorit
Audio
- Frequency response
- 20Hz-25kHz
- Crossover frequencies
- 380Hz & 3.8kHz
- Effective ATL length
- 2.4m (8ft)
- Input sensitivity
- Adjustable +4 to +20dBu
Drive units
- LF driver
- 250mm/10" PMC Carbon Fibre/Nomex piston driver
- MF driver
- 75mm soft dome midrange, 200W
- HF driver
- 34mm soft dome tweeter, 200W
Amplification
- HF amplifier power
- 200W
- MF amplifier power
- 200W
- LF amplifier power
- 565W
Inputs
- Analogue inputs
- Balanced analogue main input/through; balanced analogue LFE input/through
- Digital inputs
- AES3 main input/through; AES3 LFE input/through
- Digital input format
- AES3 96kHz 24bit
- Input impedance
- 20k balanced
Physical
- Height
- 740mm (29.1")
- Width
- 330mm (13.0")
- Depth
- 549mm (21.6")
- Weight
- 46.5kg (102.3lbs)
Warranty
- Extended warranty
- 20 years with registration within 10 days of purchase
