Kuvaus
This analog overdrive pedal aims at the punchy, clear character of classic Black Panel Fender amplifiers. The gain stage is built around a JRC4558 chip, and an op-amp section shapes the response to imitate how those tube amps break up. The result is a glassy drive that keeps the character of the guitar, adding sustain and natural compression.
A saturation trimmer sets how much drive is available. The pedal uses true-bypass hardware switching, so the signal path is left untouched when it is turned off. The design is credited as inspired by the VEMURAM Jan Ray.
It runs from a 9 V DC supply or a 9 V battery and draws under 20 mA. Input impedance is 1M Ohms and output impedance is 10K Ohms. The enclosure measures 121 x 77 x 48 mm and weighs 230 g. User manuals are offered in English, French, Italian and Japanese.
Tekniset tiedot
- Merkki
- NUX
- Malli
- 6ixty5ive OD
- Luokka
- Efektit ja pedaalit
Audio
- Circuit
- Analog
- Gain stage
- JRC4558
- Input impedance
- 1M Ohms
- Output impedance
- 10K Ohms
- Bypass
- True-bypass hardware switching
Controls
- Saturation
- Trimmer
Power
- Power
- 9 Volt DC/9V Battery
- Current draw
- < 20 mA
Physical
- Dimensions
- 121(L) * 77(W) * 48(D) mm
- Weight
- 230g
Software
- Manuals
- English, French, Italian, Japanese
Features
- Series
- Reissue Series
- Tone model
- Classic Fender Black Panel overdrive
- Inspiration
- VEMURAM Jan Ray
